Minimal test plugin for dynamic digitization. More...

#include <gplugin_test_example.h>

Public Member Functions
bool	defineReadoutSpecsImpl () override
	Defines readout specifications for this example plugin.

bool	loadConstantsImpl (int runno, std::string const &variation) override
	Loads example constants used by this plugin.

bool	loadTTImpl (int runno, std::string const &variation) override
	Builds a minimal in-memory translation table for the example.

std::unique_ptr< GDigitizedData >	digitizeHitImpl (GHit *ghit, size_t hitn) override
	Digitizes the provided hit into a small example output record.

	GDynamicDigitization (const std::shared_ptr< GOptions > &g)
	Inherit the base constructor (const std::shared_ptr<GOptions>&).

Public Member Functions inherited from GDynamicDigitization
	GDynamicDigitization (const std::shared_ptr< GOptions > &g)
	Constructs the digitization base object.

virtual	~GDynamicDigitization ()=default
	Virtual destructor.

double	processStepTime (const std::shared_ptr< GTouchable > &gTouchID, G4Step *thisStep)
	Computes the time associated with a simulation step for electronics binning.

virtual double	processStepTimeImpl (const std::shared_ptr< GTouchable > &gTouchID, G4Step *thisStep)
	Implementation hook for step time computation.

std::vector< std::shared_ptr< GTouchable > >	processTouchable (std::shared_ptr< GTouchable > gtouchable, G4Step *thisStep)
	Processes a touchable based on the current step and readout specs.

virtual std::vector< std::shared_ptr< GTouchable > >	processTouchableImpl (std::shared_ptr< GTouchable > gtouchable, G4Step *thisStep)
	Implementation hook for touchable processing.

std::vector< std::shared_ptr< GTouchable > >	processGTouchableModifiers (const std::shared_ptr< GTouchable > &gTouchID, const GTouchableModifiers &gmods)
	Applies touchable modifiers.

virtual std::vector< std::shared_ptr< GTouchable > >	processGTouchableModifiersImpl (const std::shared_ptr< GTouchable > &gTouchID, const GTouchableModifiers &gmods)
	Implementation hook for touchable modifier application.

std::unique_ptr< GTrueInfoData >	collectTrueInformation (GHit *ghit, size_t hitn)
	Collects standardized “true hit information” into a GTrueInfoData record.

virtual std::unique_ptr< GTrueInfoData >	collectTrueInformationImpl (GHit *ghit, size_t hitn)
	Implementation hook for true-information collection.

std::unique_ptr< GDigitizedData >	digitizeHit (GHit *ghit, size_t hitn)
	Digitizes a hit into a GDigitizedData record.

bool	loadConstants (int runno, std::string const &variation)
	Loads digitization constants (calibration/configuration).

bool	loadTT (int runno, std::string const &variation)
	Loads the translation table (identity -> electronics address).

void	chargeAndTimeAtHardware (int time, int q, const GHit *ghit, GDigitizedData &gdata)
	Adds hardware-level time/charge and address fields to a digitized record.

bool	defineReadoutSpecs ()
	Initializes readout specifications.

virtual bool	decisionToSkipHit (double energy)
	Decides whether a hit should be skipped based on deposited energy.

void	set_loggers (const std::shared_ptr< GOptions > &g)
	Sets the options pointer required by the digitization base.

Public Member Functions inherited from GBase< GDynamicDigitization >
	GBase (const std::shared_ptr< GOptions > &gopt, std::string logger_name="")

	GBase (const std::shared_ptr< GLogger > &logger)

	GBase (const GBase &)=default

	GBase (GBase &&) noexcept=default

virtual	~GBase ()

GBase &	operator= (const GBase &)=default

GBase &	operator= (GBase &&) noexcept=default

Additional Inherited Members
Static Public Member Functions inherited from GDynamicDigitization
static GDynamicDigitization *	instantiate (const dlhandle h, std::shared_ptr< GOptions > g)
	Dynamically instantiates a plugin instance from a dynamic library.

Data Fields inherited from GDynamicDigitization
std::shared_ptr< const GReadoutSpecs >	readoutSpecs
	Readout specs are created during initialization and treated as immutable.

std::shared_ptr< const GTranslationTable >	translationTable
	Translation table is typically loaded during initialization and treated as immutable.

Protected Member Functions inherited from GDynamicDigitization
void	check_if_log_defined () const
	Ensures options/logging are configured before plugin methods run.

Protected Attributes inherited from GDynamicDigitization
std::shared_ptr< GOptions >	gopts
	Options used by the digitization plugin instance.

Protected Attributes inherited from GBase< GDynamicDigitization >
std::shared_ptr< GLogger >	log

Detailed Description

This class is designed for:

demonstrating the plugin surface expected by gdynamic digitization
serving as a small integration test for the dynamic loader

It stores a few example configuration variables (scalar/array/vector/string) and creates a small translation table in memory.

Definition at line 36 of file gplugin_test_example.h.

Member Function Documentation

◆ defineReadoutSpecsImpl()

bool GPlugin_test_example::defineReadoutSpecsImpl ( )

overridevirtual

This is the minimal required hook that every plugin must implement. The routine demonstrates assigning:

a fixed electronics time window
a grid start time (time-grid origin)
a hit bitset controlling which hit fields are computed/stored

Returns: true when readout specifications are assigned.

Implements GDynamicDigitization.

Definition at line 7 of file gplugin_test_example.cc.

◆ digitizeHitImpl()

std::unique_ptr< GDigitizedData > GPlugin_test_example::digitizeHitImpl	(	GHit *	ghit,
		size_t	hitn )

overridevirtual

This example demonstrates:

creating a GDigitizedData record
computing a "voltage" from total deposited energy
building a synthetic "digi_time" by scaling and summing hit step times

Parameters

ghit	Input hit to digitize. Ownership stays with the caller.
hitn	Hit index (unused in this example).

Returns: Newly allocated digitized record.

Reimplemented from GDynamicDigitization.

Definition at line 60 of file gplugin_test_example.cc.

◆ GDynamicDigitization()

GDynamicDigitization::GDynamicDigitization ( const std::shared_ptr< GOptions > & g )

inlineexplicit

Definition at line 167 of file gdynamicdigitization.h.

◆ loadConstantsImpl()

bool GPlugin_test_example::loadConstantsImpl	(	int	runno,
		std::string const &	variation )

overridevirtual

This routine demonstrates how a plugin can initialize internal configuration state (members) that later influences digitization.

It sets:

var1 : scalar example value
var2 : small fixed-size array example value
var3 : vector example value
var4 : string example value

Parameters

runno	Run number (used for logging in this example).
variation	Variation string (used for logging in this example).

Returns: true to indicate success.

Reimplemented from GDynamicDigitization.

Definition at line 18 of file gplugin_test_example.cc.

◆ loadTTImpl()

bool GPlugin_test_example::loadTTImpl	(	int	runno,
		std::string const &	variation )

overridevirtual

This demonstrates how a plugin can map detector identities (vectors of ints) to electronics addresses.

Parameters

runno	Unused in this example.
variation	Unused in this example.

Returns: true to indicate success.

Reimplemented from GDynamicDigitization.

Definition at line 42 of file gplugin_test_example.cc.

The documentation for this class was generated from the following files:

examples/gplugin_test_example.h
examples/gplugin_test_example.cc
